Compositional, Unconventional & Advanced Processes Simulator
GEM™ is the leading reservoir simulation software for compositional, chemical, and unconventional Equation of State (EoS) based reservoir modelling.
Accurately replicates the subsurface fluid flow and interactions to assist in field optimization and to maximize hydrocarbon recovery. GEM is widely used to capture unconventional shale liquids production and is the gold-standard simulator for CO2 and H2 storage processes.
Simulation for Unconventional Reservoirs
Simulate natural and hydraulic fractures, multi-component adsorption and desorption, geomechanical effects, inter-phase mass transfer, multi-phase diffusion and non-Darcy flow for unconventional shale as well as coal bed methane production.
Improve and Optimize Recovery Factors
Understand the impacts of key phenomena including miscible/immiscible displacement, chemical EOR, and non-steam based thermal recovery processes when improving and optimizing the recovery factor of an oil and gas asset.
Advanced Evaluation and Design
Design and evaluate the effectiveness of chemical additives with advanced cEOR features such as polymer, surfactant, foam, and ASP type enhancements.
Optimize Recovery and Reduce Environmental Impact
Maximize oil recovery and reduce environmental impact with accurate simulation of Low Salinity Waterflood (LSW) mechanisms, including geochemistry and wettability alterations, accounting for ion exchange, and zeta potential influences on the process.
CO2 Injection for Subsurface Viability Assessment
Simulate the long-term effects of carbon dioxide (CO2) injection into the subsurface environment, in particular saline aquifer or depleted hydrocarbon reservoirs, thereby helping determine the viability and reducing the risk of any CCS project
Benefits
- Capture how fluid properties and the system phase behaviour changes with pressure, temperature, and composition.
- Accurately model naturally and hydraulically fractured reservoirs.
- Utilize full physics for modelling foam and other cEOR processes.
- Capture effects of geochemistry and clay distribution when modelling LSW.
- Model geomechanical effect of stress and strain to understand effects on production.
Key Features
- Full field Equation of State (EoS) based adaptive-implicit compositional reservoir simulator.
- Massively parallel capability.
- Dynamic Gridding Refinement and Coarsening.
- Chemical EOR modelling capabilities for polymer, surfactant, ASP, foam.
- Full thermal capability including Joule Thompson effects.
- One and two-way coupled finite element geomechanics including thermal geomechanical effects.
- Flexible and extensive geochemical capability coupled with equilibrium and rate dependent reactions.
- Oil-water-gas flash with water being an active fluid allowing for any water based interactions.
- Advanced capability Tracer module for tracking individual molecules in the simulator.
- DUALPOR and DUALPERM capability, additionally coupled to explicit discrete fracture network (DFN) and hydraulic fracturing capabilities.
- Grid independent wells.
Related Resources
Take your technical skills from the classroom to your workplace
GEM™ is the leading reservoir simulation software for compositional, chemical, and unconventional Equation of State (EoS) based reservoir modelling.
Frequently Asked Questions
GEM is CMG’s Generalized Equation-of-State Modelling physics engine. It is an advanced EOS compositional reservoir simulator designed to model recovery processes where fluid composition and phase behavior are critical. It is commonly used for studies involving miscible and immiscible gas injection, volatile oil and gas condensate reservoirs, and CO₂-based enhanced recovery or storage applications.
GEM should be used when an EOS-based PVT description is required to capture compositional effects such as vaporization, swelling, and condensation. IMEX is preferred for studies that can be represented using a black-oil formulation, such as primary depletion or conventional waterflooding. STARS is intended for thermal and advanced recovery processes, including steam-based and combustion-driven methods.
GEM models CO₂ injection by tracking its interaction with reservoir fluids across phases, including compositional changes and dissolution into water. It supports key CCS mechanisms such as residual trapping, solubility trapping, and long-term geochemical interactions, enabling detailed evaluation of CO₂ storage scenarios.
Yes. GEM includes options to model aqueous and mineral reactions, such as dissolution and precipitation, within compositional systems. It can also be coupled with CMG’s geomechanics module to evaluate how fluid flow and chemical changes influence reservoir properties such as porosity and permeability.
Compositional fluid models for GEM are typically developed using WinProp, CMG’s dedicated tool for characterizing reservoir fluids and matching laboratory PVT data. Once validated, these fluid models are imported into Builder and used directly within GEM simulations.
The Process Wizard in Builder provides guided assistance for setting up complex GEM workflows such as Chemical EOR processes, low-salinity water injection, and CCS studies. It helps generate consistent simulator input structures and default parameters based on documented process models, which users can then refine using laboratory or field data.
Yes. GEM includes support for GPU-enabled simulation on supported platforms and hardware configurations. It does not require a separate license beyond a standard GEM license. Current GPU execution uses a single GPU per run, while multi-GPU support is under development.
